| >>>>>PRODUCT PARAMETERS | ||||||||||
| MODEL | INPUT (V) | POWER (W) | EFFICACY (lm/W) | LUMENS (LM) | BEAM ANGLE | TO REPLACE | DIMMING | CRI | P.F. | C.C.T. |
| CP01A-40 | 120-277 | 40 | 116 | 4640 | 135° | 100-150W HID | AVAILABLE | >80 | >0.92 | 4000K 5000K |
| CP01A-60 | 60 | 116 | 6960 | 175-250W HID | ||||||
| CP01A-75 | 75 | 103 | 7725 | 250-320W HID | ||||||
| >>>>>PACKAGING INFORMATION | ||||||||||
| MODEL | INNER BOX (mm) | MASTER CARTON (mm) | QTY/CTN | N.W. (kgs) | G.W. (kgs) | CBM (m³) | ||||
| CP01A-40 | 285*285*102 | 430*300*330 | 4 | 9.6 | 10.7 | 0.043 | ||||
| CP01A-60 | 9.9 | 11.05 | ||||||||
| CP01A-75 | 9.9 | 11.05 | ||||||||
| >>>>>PRODUCT PARAMETERS | ||||||||||
| MODEL | INPUT (V) | POWER (W) | EFFICACY (lm/W) | LUMENS (LM) | BEAM ANGLE | TO REPLACE | DIMMING | CRI | P.F. | C.C.T. |
| CP01A-40 | 120-277 | 40 | 116 | 4640 | 135° | 100-150W HID | AVAILABLE | >80 | >0.92 | 4000K 5000K |
| CP01A-60 | 60 | 116 | 6960 | 175-250W HID | ||||||
| CP01A-75 | 75 | 103 | 7725 | 250-320W HID | ||||||
| >>>>>PACKAGING INFORMATION | ||||||||||
| MODEL | INNER BOX (mm) | MASTER CARTON (mm) | QTY/CTN | N.W. (kgs) | G.W. (kgs) | CBM (m³) | ||||
| CP01A-40 | 285*285*102 | 430*300*330 | 4 | 9.6 | 10.7 | 0.043 | ||||
| CP01A-60 | 9.9 | 11.05 | ||||||||
| CP01A-75 | 9.9 | 11.05 | ||||||||
